Glycerol effect on the inhibition of spontaneous combustion of subbituminous coal

Efecto del glicerol en la inhibición de la combustión espontánea de carbón sub-bituminoso

DOI:

https://doi.org/10.15446/rbct.n40.55999

Palabras clave:

Adsorption, Coal, Isotherm, Water (en)
Adsorción, Carbón, Isoterma, Agua (es)

Descargas

Autores/as

Factors favoring the phenomenon of spontaneous combustion in coal mainly depend on the intrinsic properties such as coal particle size, moisture content, among others; the medium in which it is located and how it is stored. Consistent with this, the objective of this work is to evaluate the effect of glycerol on the inhibition of self-combustion as water re-adsorption reducer through the addition of glycerol in different amounts (4, 8, 18 and 28% wt). The coal sample was extracted from the Córdoba department, Colombia. Incipient impregnation method was used to perform the addition of glycerol to the desired quantities. Characterizing the coal samples was performed by: TGA-DTG, nitrogen adsorption at -196 °C, C-H-N-O, FTIR, and SEM. The TGA of the coals evaluated in an air atmosphere, show changes in combustion properties of each sample. Di ignition index is reduced as the coal is impregnated with glycerol, obtaining its lowest value for 8wt% of glycerol. The effect of glycerol in inhibiting the spontaneous combustion of coal is exposed in the adsorption equilibrium; the sample with 8wt% glycerol shows the highest reduction of water adsorption in coal validating the proposed technology as inhibitor agent spontaneous combustion phenomenon found in Colombian coal.
Factores que favorecen el fenómeno de auto-combustión del carbón depende principalmente de las propiedades intrínsecas, tales como tamaño de partícula, contenido de humedad, entre otros; el medio en el que se encuentra y cómo se almacena. De acuerdo con esto, el objetivo de este trabajo es evaluar el efecto del glicerol en la inhibición de auto-combustión del carbón como reductor de re-adsorción de agua, mediante la adición de glicerol en diferentes cantidades (4, 8, 18 y 28% en peso). El método de impregnación incipiente se utilizó para adicionar el glicerol a las cantidades deseadas. La caracterización de las muestras se realizó mediante: TGA-DTG, adsorción de nitrógeno a -196 ° C, C-H-N-O, FTIR, y SEM. El TGA de los carbone refleja cambios en las propiedades de combustión de cada muestra. El índice de ignición Di presenta su valor más bajo para la muestra con 8% en peso. El efecto del glicerol en la inhibición de la combustión espontánea del carbón está expuesto en el equilibrio de adsorción; la muestra con 8% en peso de glicerol presenta la mayor reducción de la adsorción de agua en el carbón validando la tecnología propuesta como agente inhibidor del fenómeno de auto-combustión en carbones colombianos.

Referencias

Rutledge, D., Hubbert’s peak, the coal question, and climate change, Excel Workbook (permission is given to copy this work provided that attribution is given and the following web link is included). Website: http://rutledge. caltech. edu, 2007.

Shafiee, S. and Topal, E., When will fossil fuel reserves be diminished?, Energy policy, 37, pp. 181-189, 2009. DOI: 10.1016/J.ENPOL.2008.08.016

Castro, J., Perspectivas de la demanda energética global, Petrotecnia, pp. 54-70, 2011.

Avila, C., Wu, T. and Lester, E., Estimating the spontaneous combustion potential of coals using thermogravimetric analysis, Energy & Fuels, 28, pp. 1765-1773, 2014. DOI: 10.1021/ef402119f

Stracher, G.B. and Taylor, T.P., Coal fires burning out of control around the world: Thermodynamic recipe for environmental catastrophe, International Journal of Coal Geology, 59, pp. 7-17, 2004. DOI: 10.1016/J.COAL.2003.03.002

Dubinin, M., Inhomogeneous microporous structures of carbonaceous adsorbents, Carbon, 19, pp. 321-324, 1981.

Dubinin, M. and Serpinsky, V., Isotherm equation for water vapor adsorption by microporous carbonaceous adsorbents, Carbon, 19, pp. 402-403, 1981.

Bowes, P., Self-heating: Evaluating and controlling the hazards: Department of the environment, building research establishment, 1984.

Carras, J.N. and Young, B.C., Self-heating of coal and related materials: Models, application and test methods, Progress in Energy and Combustion Science, 20, pp. 1-15, 1994. DOI: 10.1016/0360-1285(94)90004-3

Nalbandian, H., Propensity of coal to self-heat: IEA Clean Coal Centre London, 2010.

Krishnaswamy, S., Agarwal, P. K. and Gunn, R.D., Low-temperature oxidation of coal. 3. Modelling spontaneous combustion in coal stockpiles, Fuel, 75, pp. 353-362, 1996. DOI: 10.1016/0016-2361(95)00249-9

Küçük, A., Kadıoğlu, Y. and Gülaboğlu, M., A study of spontaneous combustion characteristics of a Turkish lignite: Particle size, moisture of coal, humidity of air, Combustion and Flame, 133, pp. 255-261, 2003. DOI: 10.1016/S0010-2180(02)00553-9

Ray, S. and Bhowmick, B., Indian coals vis-a-vis spontaneous heating problems, Journal of Mines, Metals & Fuels, 49, pp. 123-128, 2001.

Sujanti W. and Zhang, D.K., A laboratory study of spontaneous combustion of coal: The influence of inorganic matter and reactor size, Fuel, 78, pp. 549-556, 1999. DOI: 10.1016/S0016-2361(98)00188-4

Fei, Y., Aziz, A.A., Nasir, S., Jackson, W., Marshall, M.J. and Hulston, J., The spontaneous combustion behavior of some low rank coals and a range of dried products, Fuel, 88, pp. 1650-1655, 2009. DOI: 10.1016/J.FUEL.2009.03.017

Fierro, V., Miranda, J., Romero, C., Andres, J., Arriaga, A. and Schmal, D., Model predictions and experimental results on self-heating prevention of stockpiled coals, Fuel, 80, pp. 125-134, 2001. DOI: 10.1016/S0016-2361(00)00062-4

Pone, J.D.N., Hein, K.A., Stracher, G.B., Annegarn, H.J. and Finkleman, R.D. and Blake, D.R., The spontaneous combustion of coal and its by-products in the Witbank and Sasolburg coalfields of South Africa, International Journal of Coal Geology, 72, pp. 124-140, 2007. DOI: 10.1016/J.COAL.2007.01.001

Arısoy, A., Coal mine safety and preventing self-combustion of coal. In: Conference: Inerma, At Istanbul, Turkey, 2010.

Bhat, S. and Agarwal, P.K., The effect of moisture condensation on the spontaneous combustibility of coal, Fuel, 75, pp. 1523-1532, 1996. DOI: 10.1016/0016-2361(96)00121-4

Jun-Ling, X., Feng, H. and Run-Zhang, Y., Relationship between coal powder and its combustibility, Journal of Wuhan University of Technology-Mater. Sci. Ed., 17, pp. 72-75, 2002. DOI: 10.1007/BF02852641

Franco, C., Martínez, M., Benjumea, P., Patiño, E. and Cortés, F., Water remediation based on oil adsorption using nanosilicates functionalized with a petroleum vacuum residue, Adsorption Science & Technology, 32, pp. 197-208, 2014. DOI: 10.1260/0263-6174.32.2-3.197

Franco, C., Patiño, E., Benjumea, P., Ruiz, M.A. and Cortés, F., Kinetic and thermodynamic equilibrium of asphaltenes sorption onto nanoparticles of nickel oxide supported on nanoparticulated alumina, Fuel, 105, pp. 408-414, 2013. DOI: 10.1016/J.FUEL.2012.06.022

Franco, C., Montoya, T., Nassar, N.N., Pereira-Almao, P. and Cortés, F., Adsorption and subsequent oxidation of colombian asphaltenes onto nickel and/or palladium oxide supported on fumed silica nanoparticles, Energy & Fuels, 27, pp. 7336-7347, 2013. DOI: 10.1021/ef4018543

Franco, C., Nassar, N.N. and Cortés, F., Removal of oil from oil-in-saltwater emulsions by adsorption onto nano-alumina functionalized with petroleum vacuum residue, Journal of Colloid and Interface Science, 433, pp. 58-67, 2014. DOI: 10.1016/j.jcis.2014.07.011

Brunauer, S., Emmett, P.H. and Teller, E., Adsorption of gases in multimolecular layers, Journal of the American chemical society, 60, pp. 309-319, 1938.

Cortés, F., Rojano, B. and Chejne-Janna, F., Advantages and thermodynamic limitations of the experimental sorption isosteric method, DYNA, 80(182), pp. 155-162, 2013.

Parshetti, G.K., Quek, A., Betha, R. and Balasubramanian, R., TGA–FTIR investigation of co-combustion characteristics of blends of hydrothermally carbonized oil palm biomass (EFB) and coal, Fuel Processing Technology, 118, pp. 228-234, 2014. DOI: 10.1016/J.FUPROC.2013.09.010

Kaymakci, E. and Didari, V., Relations between coal properties and spontaneous combustion parameters, Turkish Journal of Engineering and Environmental Sciences, 26, pp. 59-64, 2002.

Freeman, E.S. and Carroll, B., The application of thermoanalytical techniques to reaction kinetics: the thermogravimetric evaluation of the kinetics of the decomposition of calcium oxalate monohydrate, The Journal of Physical Chemistry, 62, pp. 394-397, 1958. DOI: 10.1021/j150562a003

Arias, B., Pevida, C., Rubiera, F. and Pis, J., Changes in coal char reactivity and texture during combustion in an entrained flow reactor, Journal of Thermal Analysis and Calorimetry, 90, pp. 859-863, 2007. DOI: 10.1007/s10973-006-8265-z

Sis, H., Evaluation of combustion characteristics of different size elbistan lignite by using TG/DTG and DTA, Journal of thermal analysis and calorimetry, 88, pp. 863-870, 2006. DOI: 10.1007/s10973-005-7447-4

Allardice, D., Clemow, L., Favas, G., Jackson, W., Marshall, M. and Sakurovs, R., The characterisation of different forms of water in low rank coals and some hydrothermally dried products, Fuel, 82, pp. 661-667, 2003. DOI: 10.1016/S0016-2361(02)00339-3.

Charrière, D. and Behra, P., Water sorption on coals, Journal of colloid and interface science, 344, pp. 460-467, 2010. DOI: 10.1016/j.jcis.2009.11.064

Chen, X.D., A new water sorption equilibrium isotherm model, Food research international, 30, pp. 755-759, 1997. DOI: 10.1016/S0963-9969(98)00042-8

Karthikeyan, M., Minimization of moisture readsorption in dried coal samples, Drying Technology, 26, pp. 948-955, 2008. DOI: 10.1080/07373930802142846

Marchessault, R., Application of infra-red spectroscopy to cellulose and wood polysaccharides, Pure and Applied Chemistry, 5, pp. 107-130, 1962. DOI: 10.1351/pac196205010107

McCain, W.D., The properties of petroleum fluids: PennWell Books, 1990.

Shigehisa, T., Inoue, T. and Kumagai, H., Mathematical model of water sorption isotherms of UBC, Fuel Processing Technology, 131, pp. 133-141, 2015. DOI: 10.1016/J.FUPROC.2014.11.023

Talu, O. and Meunier, F., Adsorption of associating molecules in micropores and application to water on carbon, AIChE Journal, 42, pp. 809-819, 1996. DOI: 10.1002/aic.690420319

Dimensions

PlumX

Visitas a la página del resumen del artículo

859

Descargas

Los datos de descarga aún no están disponibles.

Cómo citar

Taborda Acevedo, E. A., Jurado Valencia, W. J., & Cortés, F. B. (2016). Efecto del glicerol en la inhibición de la combustión espontánea de carbón sub-bituminoso. Boletín De Ciencias De La Tierra, 40, 64-74. https://doi.org/10.15446/rbct.n40.55999
