Modelo biobjetivo para el problema de localización de centros de auxilio y distribución de productos en situaciones de respuesta a desastres

A bi-objective model for the location of relief centers and distribution of commodities in disaster response operations

Palabras clave:

optimización biobjetivo, logística humanitaria, localización-distribución, dimensionamiento de flota, programación estocástica (es)
bi-objective optimization, humanitarian logistic, location-distribution, fleet sizing, stochastic programming (en)

Descargas

Autores/as

Las consecuencias de los desastres naturales en los últimos años han evidenciado la complejidad de esos eventos. Entre las decisiones importantes en situaciones de desastres están la localización de centros de auxilio, la distribución de productos y el dimensionamiento de flota. La ejecución de estas operaciones puede implicar objetivos contradictorios, principalmente, costos logísticos y costos por demanda insatisfecha. Por un lado, minimizar la demanda insatisfecha lleva a mayores costos logísticos. Por otro lado, minimizar los costos logísticos sin considerar la demanda insatisfecha implica un atendimiento ineficaz en las áreas afectadas. En este artículo es desarrollado un modelo biobjetivo de programación estocástica para el problema integrado de localización-distribución y dimensionamiento de flota. Se solucionan instancias basadas en el megadesastre de la región Serrana de Rio de Janeiro en 2011. Las soluciones del modelo biobjetivo son comparadas con una versión mono-objetivo del mismo, resaltando las ventajas y desventajas de cada modelo.
Consequences of natural disasters in recent years have shown the complexity of these situations. In disaster situations, the location of relief centers, the distribution of supplies and the fleet sizing are some of the most important decisions. In most cases the execution of this operations lead to contradictory objectives, mainly, logistic costs and unmet demand costs. On the one hand, minimize unmet demand implies higher logistics costs. On the other hand, minimize logistics costs without considering the unmet demand may lead with an inefficient attendance in the affected areas. In this paper, we propose a bi-objective stochastic programing model for the integrated problem of location-distribution and fleet sizing. We solve instances based on the mega disaster in the Mountain Region of Rio de Janeiro in 2011. We compare the solutions of a bi-objective model in respect to solutions of a mono-objective version, highlighting the advantages and disadvantages of each model.

Referencias

EM-DAT. The international disaster database, 2016.

Busch A. e Amorim S., A tragédia da região serrana do Rio de Janeiro em 2011: Procurando respostas. ENAP, pp. 1-20, 2011.

Carvajal-Escobar, Y., Inundaciones en Colombia. ¿Estamos preparados para enfrentar la variabilidad y el cambio climático?. Memorias, 9(16), pp. 105-119, 2011.

Mete, H.and Zabinsky, Z. Stochastic optimization of medical supply location and distribution in disaster management. Int. J. Production Economics, 126 (1), pp. 76-84, 2010. DOI:10.1016/j.ijpe.2009.10.004.

Cavalcanti, L., Leiras, A., Yoshizaki, H., Mendes, A. e Montibeller, G., Critérios de desempenho para distribuição de suprimentos em ações humanitárias. Proceedings of XLVI SBPO, 2014.

Altay, N. and Green, W., OR/MS research in disaster operations management. European Journal of Operational Research, 175(1), pp. 475-493, 2006. DOI:10.1016/j.ejor.2005.05.016.

Galindo, G. and Batta, R., Review of recent developments in OR/MS research in disaster operations management. European Journal of Operational Research, 230(2), pp. 201-211, 2013. DOI:10.1016/j.ejor.2013.01.039.

De la Torre, L., Dolinskaya, I. and Smilowitz, K., Disaster relief routing: Integrating research and practice. Socio-Economic Planning Sciences, 46(1), pp. 88-97, 2012. DOI:10.1016/j.seps.2011.06.001.

Ortuño, M., Cristobal, P., Ferrer, J., Martin-Campo, F., Muñoz, S., Tirado, G, et al., Decision aid models for disaster management and emergencies. Atlantis Computational Intelligence Systems, 7, pp. 1-45, 2013. DOI:10.2991/978-94-91216-74-9.

Zheng, Y., Chen, S. and Ling, H., Evolutionary optimization for disaster relief operations: A survey. Applied Soft Computing, 27, pp. 553-566, 2014. DOI:10.1016/j.asoc.2014.09.041.

Ozdamar, L. and Ertem, M., Models, solutions and enabling technologies in humanitarian logistics. European Journal of Operational Research, 244(1), pp. 55-65, 2015. DOI: 10.1016/j.ejor.2014.11.030.

Barbarosoglu, G. and Arda, Y., A two-stage stochastic programming framework for transportation planning in disaster response. JORS, 55(1), pp. 43-53, 2004. DOI:10.,/palgrave.jors.2601652.

Lodree, E., Ballard, K. and Song, C. Pre-positioning hurricane supplies in a commercial supply chain. Socio-Economic Planning Sciences, 46(4), pp. 291-305, 2012. DOI:10.1016/j.seps.2012.03.003.

Kelle ,P., Schneider, H. and Yi, H., Decision alternatives between expected cost minimization and worst case scenario in emergency supply – Second revision. International Journal of Production Economics, 157, pp. 250-260. DOI:10.1016/j.ijpe.2014.06.009.

Salman, F. and Gunnec, D., A two-stage multi-criteria stochastic programming model for location of emergency response and distribution centers. Proceedings of the INOC, 2007.

Rawls, C. and Turnquist, M., Pre-positioning of emergency supplies for disaster response. Transportation Research Part B, 44(4), pp. 521-534, 2010. DOI:10.1016/j.trb.2009.08.003.

Rawls, C. and Turnquist, M., Pre-positioning and dynamic delivery planning for short-term response following a natural disaster. Socio-Economic Planning Sciences, 46(1), pp. 46-54, 2012. DOI:10.1016/j.seps.2011.10.002.

Bozorgi-Amiri, A., Jabalameli, M., Alinaghian, M. and Heydari, M., A modified particle swarm optimization for disaster relief logistics under uncertain environment. The International Journal of Advanced Manufacturing Technology, 60(1), pp. 357-371, 2011. DOI:10.1007/s00170-011-3596-8.

Duran, S., Gutierrez, M. and Keskinocak, P., Pre-positioning of emergency items for CARE international. Interfaces, 41, pp. 223-237, 2011. DOI:10.1287/inte.1100.0526.

Noyan, N., Risk-averse two-stage stochastic programming with an application to disaster management. Computers & Operations Research, 39(3), pp. 541-559, 2012. DOI:10.1016/j.cor.2011.03.017.

Brito, I., Leiras, A. and Yoshizaki, H., Stochastic optimization applied to the pre positioning of disaster relief supplies decisions in Brazil. 24th Annual Conference of the POMS, 2013.

Davis, L., Samanlioglu, F., Qu, X. and Root, S., Inventory planning and coordination in disaster relief efforts. International Journal of Production Economics, 141(2), pp. 561-573, 2013. DOI:10.1016/j.ijpe.2012.09.012.

Salmerón, J. and Apte, A., Stochastic optimization for natural disaster asset prepositioning. Production and Operations Management, 19(5), pp. 561-574, 2010. DOI:10.1111/j.1937-5956.2009.01119.x.

Bataglin, L. e Alem, D., O problema de localização-distribuição no megadesastre da região Serrana no Rio de Janeiro. Gestão & Produção, 21(4), pp. 865-881, 2014. DOI: 10.1590/0104-530X834-11.

Ahmadi, M., Seifi, A. and Tootooni, B., A humanitarian logistics model for disaster relief operation considering network failure and standard relief time : A case study on San Francisco district. Transportation Research Part E, 75, pp. 145-163, 2015. DOI: 10.1016/j.tre.2015.01.008.

Rath, S., Gendreau, M. and Gutjahr, W., Bi-objective stochastic programming models for determining depot locations in disaster relief operations. International Transactions in Operational Research, 23(6), pp. 997-1023, 2016. DOI:10.1111/itor.12163.

Tzeng, G., Cheng, H. and Huang, T., Multi-objective optimal planning for designing relief delivery systems. Transportation Research Part E, 43(6), pp. 673-686, 2007. DOI:10.1016/j.tre.2006.10.012.

Vitoriano, B., Ortuño, M., Tirado, G. and Montero, J., A multi-criteria optimization model for humanitarian aid distribution. Journal of Global Optimization, 51(2), pp. 189-208, 2010. DOI:10.1007/s10898-010-9603-z.

Liberatore, F., Ortuño, M., Tirado, G., Vitoriano, B. and Scaparra, M., A hierarchical compromise model for the joint optimization of recovery operations and distribution of emergency goods in Humanitarian Logistics. Computers & Operations Research, 42, pp. 3-13, 2014. DOI:10.1016/j.cor.2012.03.019.

Bozorgi-Amiri, A., Jabalameli, M. and Mirzapour, S., A multi-objective robust stochastic programming model for disaster relief logistics under uncertainty. OR Spectrum, 35(4), pp. 905-933, 2013. DOI: 10.1007/s00291-011-0268-x.

Arango, M. and Zapata, J.,Multiobjective model for the simultaneous optimization of transportation costs, inventory costs and service level in goods distribution. IEEE Latin America Transactions, 15(1), pp. 129-136, 2017. DOI: 10.1109/TLA.2017.7827916.

Anandalingam, G. and Friesz, T., Hierarchical optimization: An introduction. Annals of Operations Research, 34. 1992. DOI: 10.1007/BF02098169.

Romero, C., Handbook of Critical Issues in Goal Programming, 1991. DOI: 10.1016/B978-0-08-040661-9.50008-7.

Haimes, Y., Lasdon, L. and Wismer, D., On a bicriterion formulation of the problems of integrated system identification and system optimization. IEEE Transactions on Systems, 1(3), pp. 296-297, 1971. DOI:10.1109/TSMC.1971.4308298.

Moreno, A., Alem, D. and Ferreira, D., Heuristic approaches for the multiperiod location-transportation problem with reuse of vehicles in emergency logistics. Computers & Operations Research, 69, pp. 79-96, 2016. DOI: 10.1016/j.cor.2015.12.002.

Dourado, F., Arraes, T., Fernandes, M. e Silva, M., O megadesastre da Região Serrana do Rio de Janeiro – As causas do evento, os mecanismos dos movimentos de massa e a distribuição espacial dos investimentos de reconstrução no pós-desastre. Anuario IGEO-UFRJ,35, pp. 43-54, 2012.

Rio De Janeiro. Resolução No 09/2011 da Assembléia Legislativa, 2011.

Alem, D., Clark, A. and Moreno, A., Stochastic network models for logistics planning in disaster relief. European Journal of Operational Research, 255(1), pp. 187-206, 2016. DOI: 10.1016/j.ejor.2016.04.041.

IBGE Brasil. Pesquisa nacional por amostra de domicílios síntese de indicadores. 2009.

ICRC. Emergency items catalogue. 2009.

The Sphere Project. Humanitarian charter and minimum standards in humanitarian response. Northampton: Belmont Press Ltd; 2011.

Cómo citar

[1]
“Modelo biobjetivo para el problema de localización de centros de auxilio y distribución de productos en situaciones de respuesta a desastres”, DYNA, vol. 84, no. 200, pp. 356–366, Jan. 2017, doi: 10.15446/dyna.v84n200.54810.
